KEYING Mounted Head adopts imported raw materials and equipment through special process manufacturing, automatic production, excellent quality. We have ceramic grinding heads of various sizes and shapes. Applications include repairing welds, remachining aircraft turbine blades, and regrinding welds in tool and die manufacturing, ranging from grinding slots and grooves in hard-to-reach areas to machining holes and rough surfaces. The diversified manufacturing process meets the special requirements of high precision industries such as high-speed railway, aviation and hardware casting.

Shape：

2. Cylindrical: suitable for workpiece grinding drilling
4. Tapering: used for grinding on chamfered surfaces and for grinding parts that require constant adjustment of the grinding position during grinding
6. Peach shape: suitable for machining small and irregular holes
8. Sphericity: suitable for polishing small and irregular holes
10. T shape: suitable for large area grinding workpiece
12. Triangular cone: suitable for machining small and irregular holes of workpiece
14. Disc shape: suitable for irregular grinding surface
16. Cylinder + semicircle: suitable for deburring and grinding of all kinds of workpiece
18. Bowl shape: ideal for work on profiles, planes and ledges without damaging round workpiece surfaces

Abrasive：

2. Brown corundum: widely used in the rough grinding of ordinary steel, such as: carbon steel, general alloy steel, malleable iron, hard bronze and so on.
4. White corundum: suitable for grinding steel with high hardness, such as high speed steel, high carbon steel, hardened steel, alloy steel and so on
6. Single crystal corundum: can be used to grind hard and tough hard grinding metal materials, such as stainless steel, high vanadium high speed steel, heat resistant alloy steel and easy deformation, easy to burn workpiece, considering that single crystal corundum abrasive is limited by production conditions, generally only recommended for the grinding of heat resistant alloy and wear-resistant metal materials
8. Chrome corundum: the application range is similar to white corundum, especially suitable for fine grinding and forming grinding of various tools, measuring tools and instrument parts. Generally, chrome corundum has better grinding performance than white corundum
10. Zirconium corundum: zirconium abrasive is mainly used for heavy load grinding, suitable for grinding heat-resistant alloy steel, titanium alloy steel and austenitic stainless steel, etc
12. Black corundum: mostly used for free grinding, such as grinding or rough grinding before electroplating products, also used for making coated abrasives, resin cutting pieces, polishing blocks and so on
14. Silicon carbide: widely used in grinding optical glass, stone, hard alloy, titanium alloy and bearing steel grinding polishing, high-speed steel tool grinding and so on
16. Black silicon carbide: widely used in non-ferrous metal (copper, aluminum) cast iron workpiece, glass, ceramic, stone and refractory products
