M14 Flap Wheel D=115
The model of this non-standard customized Flap wheel is M14 Screw Hole Type, the middle hole is 14mm screw hole. The middle of the Flap wheel is made of imported high-quality special glue, and the middle hole is made of thread. KEYING Flap wheel with Shank is a consumable industrial product of polishing and grinding head series in China abrasive and abrasive market, which is a kind of machining accessories. KEYING considers that due to the different use and particularity of the workpiece in industrial processing, the conventional type of Flap wheel with Shank cannot be satisfied, so we support sample processing and map processing. In order to improve the application ability of Mounted Flap wheel in processing, customized for customers.
1.Simple operation, no need to remove the link bar
2.Quick installation, just follow the thread direction to replace the wheel
3.Work efficiently and save time
4.The minimum speed can reach 18000, super industrial grade, Blades will not break and fly out when operating at super high speed
| Brand | KEYING | Origin Country | China | Product Code | H + Screw Hole + 115*20 + M14 + 180 + AO ↓ ↓ ↓ ↓ ↓ ↓ M8 Flap Wheel Hole Type Size(mm) D * H Model Grit(#) Raw Material |
| Diameter | 115mm | Hole Diameter | 14mm | Raw Material | Aluminium Oxide、Silicon Carbide Zirconium Corundum, Ceramic Alumina |
| Thickness | 20mm | Glue Type | High Quality Special Glue | Cloth | High quality domestic cloth Pure imported cloth |
| Maximum Speed | 25000RPM | Grit | 60#、80#、100#、120#、150# 180#、240#、320#、400#、600# | ||
| Application | Widely used in various metal surface treatment, rust removal, deburring, cleaning welding scar, cleaning coating, polishing, polishing and brightening, paint pretreatment, etc | ||||
| Applicable Tools | Electric tools, pneumatic tools, electric mill, manipulator and other tools | ||||
| Applicable Material | Stainless steel, metal, non-ferrous metal, aluminum alloy products, cast iron, etc | ||||
| Applicable Industry | Casting parts processing, hardware, metal parts, auto parts, aviation manufacturing, high-speed car and shipbuilding manufacturing processing and other high precision polishing industry. | ||||
| Grit Guide | ||||||||
| 40 | 60 | 80 | 120 | 180 | 240 | 320 | 400 | 600 |
| Preliminary processing of severe surface scratches | | | | | | | | |
| Remove rough burrs or bumps | | | | | | | | |
| Grind deeper kaser engraving marks or a brasive groove faces | | | | | | | | |
| Clean up rust, nicks or welds | | | | | | | | |
| | Pre-painting before painting | | | | | | | |
| | Medum-term polishing and smoothing | | | | | | | |
| | | Sight scratches or brushed finishes | | | | | ||
| | | | | Fine grindng and polishing | | | | |
| | | | | | Finishing and translucent processing of various metal surfaces | | ||
| | | | | | | | Mirror processing | |
